Required material for installation:
• 2 suitable cross-section sheaths (1 sheath for the power supply cable), 1 sheath for the speaker cables,
REMOTE, RCA signal and REMOTE CONTROL cables)
• Multimeter (voltage/amperage)
• Soldering iron + tin
• Crimping tool
• Stripping pliers
• Wire cutter
• Spanner for battery terminal
• Hand drill and assorted drills
• Heat sheaths of suitable diameter for the different cables
• Power cable of suitable length and section
• Remote turn on cable (REM input of amplifier) of suitable length and section
• Ground cable of suitable length and section
• Assorted connectors
• Fuse holder and suitable fuse
• Joint tag for the battery’s positive (+) terminal
• Joint tag for the vehicle’s chassis (-)
• Screw with minimum 6mm screw head and its nut for ground connection to the chassis of the vehicle
FOCAL POWER SYMMETRIC AMPLIFIERS
User manual
4
