INTEGRATION IBUS 2.1 - FLAT SUBWOOFER + 2 CHANNELS
AMPLIFIER
/ User manual
4
If your car radio is without ISO connector, you must get an ISO adapter.
Installation
Traditional wiring:
A
Power supply wire +12 Volts (Red)
F
Speaker connector
B
Ground cable (Black)
G
High level connector
C
Remote cable (Blue)
H
Power supply connector and car speakers
D
Power supply connector
I
Car radio connectors
E
Power supply connector and speakers
J
Remote control wire
K
Remote control
Photo legend page 12
