12
SOLID AMpLIfIer
User manual
Due to constant technological advances, Focal reserves its right to modify the product technical specifications without notice.
Solid 1 Solid 2 Solid 4
Nominal power measured at 14.4V
continuously under 4 Ohms
THD + N < 1%
1 x 300W 2 x 75W 4 x 75W
Signal/ Noise ratio
(1 Watt Output) A - weighted filter
> 85dB (A) > 77dB (A) > 80dB (A)
Nominal power measured at 14.4V
continuously under 2 Ohms
THD + N < 1%
1 x 470W 2 x 100W 4 x 100W
Power in bridged mode measured at
14.4V continuously under 4 Ohms
THD + N < 1%
- 1 x 200W 2 x 200W
Nominal power measured at 14.4V
continuously under 1 Ohm
THD + N < 1%
1 x 600W
(SPL mode/5min only)
- -
THD + N @ 4 Ohms
0,01% @ 50Hz 0,02% @ 1kHz 0,02% @ 1kHz
Signal/Noise ratio (RMS)
> 100dB (A) > 95dB (A) > 100dB (A)
Damping factor at 4 Ohms
50 to 50Hz 100 to 1kHz 50 to 1kHz
Frequency response
10Hz – 150Hz 10Hz – 60kHz 10Hz – 60kHz
Input impedance
20k 20k 20k
Input sensitivity
0.2 – 5V 0.2 – 5V 0.2 – 5V
High-pass filter
50 – 150Hz (12dB/oct.) 50 – 150Hz (12dB/oct.)
Low-pass filter
50 – 150Hz (12dB/oct.) 50 – 150Hz (12dB/oct.) 50 – 150Hz (12dB/oct.)
SUBSONIC filter
35Hz (24dB/oct.) - -
Remote control
Yes - Yes
Adjustable BASS BOOST level
0 to +9dB (50Hz) - -
Variable phase
0 or180° - -
Maximum gauge of the speaker cables
10mm
2
7AWG
10mm
2
7AWG
10mm
2
7AWG
Maximum gauge of the power cables
35mm
2
2AWG
35mm
2
2AWG
35mm
2
2AWG
Fuse(s)
2 x 25A 1 x 25A 2 x 25A
Protections
Short-circuit Short-circuit Short-circuit
Thermal overload Thermal overload Thermal overload
Overvoltage Overvoltage Overvoltage
Polarity reversal Polarity reversal Polarity reversal
Dimensions (HxLxW)
1.77x11.81x7.87˝
(45 x 300 x 200mm)
1.77x8.66x7.87˝
(45 x 220 x 200mm)
1.77x11.81x7.87˝
(45 x 300 x 200mm)
