To operate the fire, the left switch must be turned on first, followed by the second switch to start the blower, if required. To obtain heat
from the appliance, the
I
switch must then be operated for LOW (1kW) of heat, followed by the
II
switch for the HIGH setting. It is not
possible to obtain heat from the appliance without first switching on the main power switch (OI) and the fan blower switch (*) in con-
junction with either the LOW (
I
) or both the LOW and HIGH (
II
) switches.
SAFETY CUTOUT SYSTEM
This appliance has a safety cutout system fitted, which will activate if the air inlets or outlets are obstructed. For safety reasons the fire will
NOT switch on again automatically, the following procedure must be carried out before the fire can be operated.
NOTE: TThe vvisual eeffect wwill rremain ooperational iif tthe ccutout iis aactivated; oonly tthe ffan hheater iis pprevented ffrom wworking.
Switch OFF the appliance
at tthe wwall ssocket oor ooutlet.
Leave the fire OFF for a period of no less than 10 minutes, ensuring all
obstructions are removed. Switch the appliance ON
at tthe wwall.
Ensure the appliance is turned ON at the control switches. If the fire fails
to operate correctly, repeat the above procedure. If an attempt to switch on the appliance is made before the safety cutout has reset, the
appliance may cutout for a further period of time. If the sequence has been followed correctly and the appliance still fails to function, check
the fuse in the wall outlet. If this is not the cause, call an electrician or maintenance engineer.
MAINTENANCE
ALWAYS DDISCONNECT TTHE AAPPLIANCE FFROM TTHE MMAINS SSUPPLY BBEFORE UUNDERTAKING AANY MMAINTENANCE.
Excluding lamps and fuses, use only genuine spare parts available from your supplier. Replacement lamps must be of the same wattage
and specification as those stated in Section 3.0 Appliance Data.
Replaccing tthe llight bbulb.
The fuel effect bulb can be replaced by firstly placing the fire front to one side and then by following the steps described.
1. Disconnect the appliance from the mains.
2. Remove the frame and pebbles. Withdraw the fuel bed by firstly, removing the screw that secures it to the appliance shelf and
then pulling it gently towards you.
3. Remove the light bulb. Note that the bulb has a conventional bayonet fitting. Replace with a new bulb. A conventional
clear type bulb rated no greater than 100 Watts is suitable.
4. Refit the fuel bed.
5. Replace the frame.
CLEANING
There is no specific requirement for care of the fire other than a regular cleaning of the general appliance.
Stainless steel areas may be cleaned using a soft damp cloth or a stainless steel cleaner.
IMPORTANT -
Always clean in the direction of
the grain and never across it, as this will scratch the surface. It is recommended that a small, inconspicuous area is attempted before clean-
ing the entire stainless steel area - to ensure the cleaning material is suitable. Be careful when removing the frame as the loose coals may
become dislodged.
Painted areas may be cleaned using a dry cloth.
The area around the fire should be kept free of lint, animal hair and other extraneous material that may be drawn in to the workings of
appliance and could affect its performance.
SPARES
Refer to Section 3.0 Appliance Data for lamp and fuse specification. Excluding lamps and fuses, use only genuine manufacturers spare
parts available from your supplier.
