Fodenn IPC-BT35 - Page 7

7 / 9
Fodenn Electronic Technology Co.,Ltd
Add: 3rd floor, Building B, Runchang industrial park, Zhonghao 2 road,
Bantian street, Longgang district, Shenzhen
Tel：0755-86329789 Fax：0755-83689236 Email：oversea1@fodenn.com
2
PIN
Definition
1
+12V
2
+12V
3
BACKLIGHT_ADJ
4
PWM
5
GND
6
GND
6
PIN 1
3
2.3.3 INVERT(6-PIN):LVDS invert Parameter definition
2.3.4 EDP Display output (30-PIN): parameter definition
29 30
2.4 2.4 Built-in function interface of the board
2.4.1 F_AUDIO(4-PIN)：Amplifier PIN definition
2 4
PIN
Definition
PIN
Definition
1
VCC
16
TX3+
2
VCC
17
GND
3
VCC
18
GND
4
DET
19
AUX-
5
GND
20
HPD
6
GND
21
AUX+
7
TX0-
22
GND
8
TX1-
23
GND
9
TX0+
24
GND
10
TX1+
25
12V
11
GND
26
12V
12
GND
27
BKON
13
TX2-
28
5V
14
TX3-
29
BKCTL
15
TX2+
30
GND
PIN
Definition
1
LLINE2-R+
2
LLINE2-R-
3
LLINE2-L+
4
LLINE2-L-
