ImagePRO - HD connectivity diagram
Serial Contr
ol
(RS-232 / Ethernet)
VIDEO OUTPUTS
Betacam VTR
NTSC/PAL
PC/Mac
(XVGA/DVI)
Video
Projector
NTSC/P
al
Monitor
HD OUTPUTS
HD MonitorHD Recorder
Plasma
Display
VIDEO INPUTSVIDEO INPUTS
HD Player
HD Camera
HD INPUTS
DVD
Player
NTSC/P
al
Betacam VTR
NTSC/P
al/SDI
Camera
NTSC/P
al/SDI
PC
(VGA/XVGA)
PC/Mac
(DVI)
System applications
NTSC/PAL Monitor VGA/XVGA
Video Projector
Other Output
Applications
NTSC/PAL/HD VTR
• LED Wall Processing • Down Converter
• 24 Frame Per Second Playback • Up Converter
• Tiled display • Seamless Switcher
• Transcoder • Frame Synchronizer
• Scaler • SDTV to HDTV Scaler
• NTSC/PAL Decoder • Multi-Format Synchronizer
• NTSC/PAL Encoder • Signal Processor
