www.events.barco.com
ImagePRO specifications
Barco Events USA
11101 trade Center Drive Rancho Cordova, CA 95670
Tel. 916 859 2500 - Fax 916 859 2515
email: sales.events@barco.com
31-0302000-00 - February 2005
VIDEO INPUT
Inputs (3) on ImagePRO
(4) on ImagePR
O with SDI and ImagePRO-HD
Universal Inputs (3) high bandwidth video channels support RGBHV/RGBS/RGsB computer video,
component video (SD or HDTV), S-video, or Composite video
C
onnectors
Input 1 and 2 on 15-pin HD c
onnectors with buffered loop-through
Input 3 on five BNC connectors with buffered loop-through
Digital Video Input (1) SDI input on ImagePRO-SDI model, or SDI/HDSDI input on ImagePRO-HD
C
onnectors
BNC
Digital Video (DVI) Input (1) Input 1 on DVI-I connector supports both universal analog and DVI input
with loop-through
Input R
esolution Range
V
GA (640x480), SVGA(800x600), XGA(1024x768), SXGA(1280x1204),
UXGA(1600x1200), HDTV 480p, 720p, 1080p, 1080i, 875 RS-343, 525 RS-170
Standard Resolution Video Input NTSC, PAL or SECAM
Horizontal Frequency 15 kHz to 120 kHz
Vertical Frequency 25 Hz to 120 Hz
Input Termination 75 Ohm
Input Sync Sync-on-Video, Separate C or H/V
External Sync (Genlock) Input Blackburst, Computer H/V Sync or C-sync
Connectors BNC
VIDEO OUTPUT
Outputs (4) on ImagePRO
(5) on ImagePRO-SDI
(6) on ImagePRO-HD
RGB or component video (SD or HDTV) on HD-15
RGB or component video (SD or HDTV) or composite video on five BNC
Composite video on BNC
S-video on 4-pin mini-DIN connector
SDI on BNC, ImagePRO with SDI and ImagePRO-HD models only,
or SDI/HDSDI on ImagePRO-HD
DVI output on DVI-D connector on ImagePRO-HD model only
Standard resolution video output NTSC, PAL
High re
solution output supported
VGA (640x480), S
VGA(800x600), XGA(1024x768), SXGA(1280x1204),
UXGA(1600x1200)
For Plasma Displays 1280x768, 1365x768, 1365x1024. HDTV 480p, 720p, 1080p,
1080i. 875 RS-
343, 525 RS-170
User definable video output formats supported
Sync RGBHV, RGBS, RGsB, TTL level, Polarity selectable, HDTV Tri-level Sync supported
75 ohm Output Impedance
OTHER
Remote Control Ethernet connection (with TCP/IP) or RS-232 serial port for real-time control
Physical Height
:
1.5"; Width: 17" (43.2 cm) or 19" (48.3 cm) with rack
-mount option;
Depth: 13"; Weight: 9lbs.; Shipping Weight: 13 lbs
Input Power 100-240 VAC, 47-63 Hz
Envir
onmental
Temper
ature:
0-40 degr
ees C;
Humidity: 0-
95% noncondensing
Warranty All video products are designed and tested to the highest quality standards and
are backed by a full three-year parts and labor warranty.
BR I magePRO may 04. qxd 24- 05- 2004 16: 55 Pagi na 2
