Installation
Rear Panel Connectors
NOTE: Front Panel features are shown on page 14
AUDIO
OUT
MIC
AUDIO INPUTS
76543
VIDEO OUT 1
21
VIDEO OUT 2
VIDEO INPUTS
VIDEO 6
VIDEO 7
VIDEO 4
VIDEO 5
VIDEO 2
VIDEO 3
RS232
VIDEO 1
LINE
Figure 2-1: PresentationPRO Rear Panel
AC Power connector
Video Input connectors
Audio Inputs
Video Output HD-15 connectors
RS-232 HD-15 Connector
