TECHNICAL SPECIFICATIONS
AS-13 AS-24U
CHARACTERISTICS Hi-Fi stereo amplifier.
Bass, treble and balance
c
ontrol.
Surround and stereo
loudspeaker output.
Hi-Fi stereo amplifier.
USB/SD player for MP3 files supporting
I
D3 tag.
LCD screen.
Bass, treble and balance control.
Remote control for MP3 player.
Surround and stereo loudspeaker
output.
POWER Stereo: 25 + 25 W maximum
15 + 15 W RMS at 4 Ω
12 + 12 W RMS at 8 Ω
Surround:10 + 10 W maximum
6 + 6 W RMS at 8 Ω
PROTECTION Soft start, short circuit and overload
INPUTS 3 stereo inputs: CD, tuner and aux, 2 x RCA 400 mV
OUTPUTS Loudspeakers: stereo 4-8 Ω, Spring terminals and surround, 2 x RCA
RESPONSE 20-20,000 Hz
S/N RATIO > 70 dB (A-weighting)
DISTORTION Harmonic: < 0.1%
CROSSTALK 40 dB
POWER SUPPLY 230/115 V AC, 50 W 230/115 V AC, 65 W
DIMENSIONS 200 x 68 x 160 mm depth
