English
Instruction Manual
Thank you for choosing the “Lingua FX1000” Handsfree Car Kit equipped with
Bluetooth ® T
echnology.
Model: FX1000 (Bluetooth Handsfree Car Kit-PRO)
FX1000 is a Bluetooth® Handsfree Car Kit which can perform the basic call operations
through the handy 3 keys remote control. It is fully duplex with high sound quality.
Contents
1. Equipment
2. Installation
3. Major Features
4. Specification
5. Trouble shooting
6. Operations
1. EQUIPMENT
1.1. Main Unit Kit
1.1.1. Main Unit
1.1.2. Mounting Bracket
1.1.3. Bag of screws
1.2. Remote control Kit
1.2.1. Remote control
1.2.2. Magic Tape
1.3. T cable with ISO connectors
1.4. External microphone kit
1.4.1. External microphone
1.4.2. Magic Tape
2. INSTALLATION
The system installation is shown in figure 1.
2.1. Main unit mounting method is shown in Figure 2; mounting bracket is included
in the box.
NOTE: Do not install the main unit near the heating/air conditioning system.
Protect the main unit from direct exposure to sunlight.
1
Do not enclose the main unit in a metal container, as this would affect the
quality of the Bluetooth ® connection.
2.2.
Remote control can be stucked in order to be easily reached.
2.3. External microphone installation: we suggest to fix it near to the user’s mouth
with a maximum distance of 60 cm. For best reception. One of the installation
positions for external microphone is shown in Figure1.
Figure 1 System installation
Figure 2 Main Unit Mounting
English
2
Microphone
Car Speaker
Remote
BT Mobile
Main Unit
Main Unit
Mounting
Bracket
To Next Page
