FONROCHE 6.1 - Installation Steps; Assemble Luminary on Bracket; Set the Luminary

Page 6 of 18
Assemble the luminary on the
bracket
Set the luminary
9
10
Be careful setting the nuts on
the top side of the luminary
Use a draw wire (fish-tape) to draw the connector cable of
the lantern through the bracket to the top.
For all the setup, every
screw/nut system must be
tightened to the torque advocated by FONROCHE*
*See table on page 4
1
2
