Installation Manual – POWER 365 –6.1 – 8.1 – 2020/03/18 –

Page 1 of 18

- Installation Manual -

Simple bracket solar street light 6.1 / 8.1

Table of Contents

Questions and Answers

H
Heidi MeyersAug 6, 2025
What to do if my FONROCHE Outdoor Light doesn’t work?
- P
  Patricia BlackwellAug 6, 2025
  If your FONROCHE Outdoor Light doesn't work, it might be due to several reasons. First, ensure that the solar module isn’t obstructed by stray light. Second, verify that all cable connections are properly connected and securely locked onto the Power 365 battery system unit. Lastly, if you've installed the light late in the evening, wait until the next day to allow the solar module's output voltage to reach a sufficient level.
A
Anthony LeeAug 15, 2025
Why does my FONROCHE Outdoor Light stay on during the day?
- K
  Kevin AdamsAug 16, 2025
  If your FONROCHE Outdoor Light remains on during the day, it could be due to a wrong connection of the PV to the Power 365 battery system unit. Check that the solar module is correctly connected. Alternatively, the solar module may be defective. Verify the open circuit voltage on the cable towards the module; you should measure between 30 and 40 V. If the voltage is outside this range, the module is likely damaged.
E
Eric BarronAug 27, 2025
What to do if FONROCHE 6.1 doesn’t work after several days?
- M
  mgonzalezAug 27, 2025
  If your FONROCHE Outdoor Light stops working after functioning for several days, the batteries might be discharged. Check the connections of the solar module. Ensure there is no shadow on the solar module. Also, check the tilt angle and orientation of the solar module. If it is winter, wait some days; if not, call FONROCHE Lighting for further actions.
