Foppapedretti FOLDING - Unfold the Frame; Install Front Wheels

Folding 12
1a
2b
1b
1
2
2
2
1
1c
Unfold the frame
handle bar
locking joint
2a
socket
axle
“click”
UNFOLD THE FRAME
Loosen folding hook rst,
uplift the handle as arrow 1
airection, then push the rear
bracket forward as arrow 2
until you hear a” click”, and
then depress handle bar. A”
click” will indicate unfold well.
Ensure the locking joint on
the handle bar is completely
horizontal (Fig. 1c)
INSTALL FRONT WHEELS
Keep the plastic parts of front
wheel inside and its shape
match well with the socket.
Then insert the front wheel
pin into the socket until a”
click”( Fig 2a). To detach
front wheel, please squeeze
the dismounting button on the
socket( Fig 2b).
