Force USA F-G9 - Assembly Step 3: Installing Base and Guide Rods

No.
Descripon
Note
Qty.
10
lock nut
M10
8
11
washer
Φ10
16
25
lower base
2
26
upper base
2
27
guide rod
Φ25x1850
2
28
lock sleeve
2
29
sliding sleeve
2
30
rubber pad with groove
Φ60xΦ26x45
2
31
safety hook right
1
32
safety hook le
1
33
hexagon bolt
M10x90
8
34
socket set screw
M8x10
2
35
end cap
2
36
check ring
2
37
pipe
Φ50x310xT0.5
2
38
buon head socket screw
M12x40
2
39
spring washer
Φ12
2
40
washer
Φ12
2
41
barbell rod
1
42
inner pipe
Φ48x298x2.5T
2
43
rubber pad
Φ60xΦ26x25
2
89
barbell rod ring
2
Assembly step 3
11
33
11
26
34
10
36
42
37
35
40
39
38
25
25
27
29
28
30
31
32
29
41
33
10
33
10
11
43
43
28
33
26
30
38
89
