Force USA F100 - CABLE AND ACCESSORY INTEGRATION

Assembly steps
Step
NO
Item NO Name Qty Item NO Name Qty
9
NO 9
Functional trainer right
pully
1 G Flat washer Ø10 4
NO 10
Functional trainer Left
pully
1 F Locknut M10 4
NO 37 Stainless steel conduit 2
B
Hexagon flat head screw
M10*70
4
Tools No.6 hexagon socket screw driver,wrench
The lettering surfaces of the regulating tube are installed facing inwards, the lettering sequence is from
bottom to top, and the left and right adjustment groups are assembled in the same way. Pay attention to
distinguish between No. 9 and No. 10.
17
