KEY NUMBER DESCRIPTION OF PART QUANTITY
1 Back Bottom Beam Assembly 1
2 Main Beam Tube Assembly 1
3 Guide Rod Washer 2
4 Flat Washer φ12 2
5 Lock Nut M12 2
6 Hexagon Bolt M10*120 2
7 Gear Plate 2
8 Flat Washer φ10 19
9 Lock Nut M10 10
10 Hexagon Bolt M10*80 4
11 Seat Tube Assembly 1
12 Back Cushion Tube Assembly 1
13 Back Cushion Back Support Assembly 1
14 External Thread Shaft φ12*M10*118 1
15 Shaft φ12*129.5-M10 1
16 Seat Cushion 1
17 Back Cushion 1
18 Flat Washer φ8 13
19 Spring Washer φ8 13
20 Hexagon Bolt M8*60 5
21 Kick Internal Insert Tube Assembly 1
22 Kick Frame Assembly 1
23 Foam Inner Cap φ70*φ27*12 6
24 Foam Outer Cap φ70*φ9*14 6
25 Foam φ25*φ100*175 6
26 Hexagon Socket Button Head Screw M8*25 6
PARTS LIST
