BATTERY INDICATION
Dodavatel / Importer / Поставщик
KCK Cyklosport-Mode s.r.o., U Tescomy 250, 760 01 Zlin, CZ
www.kckcyklosport.cz, , www.force.cz
Země původu Čína / Made in China / Страна происхождения Китай
Dodavatel / Importer
KCK Cyklosport-Mode s.r.o., Bartošova 348, 765 02 Otrokovice-Kvítkovice, CZ
www.kckcyklosport.cz, www.force.bike
Země původu Čína / Made in China
ART. 45176
INSTALLATION
Number of light modes: 5 – 4 light modes + 1 bell
Light intensity in lumens: *350LM
Battery life: *2-6h
Charging time: *3h
Battery type: Lithium polymer 3,7V/1200mAh
Number of charging cycles: *500
Beam type: 1x 5W Samsung LED + 12x SMD boční LED
Light weight: 66,5 g
Light weight including holder: 78 g
IP protection level: IPX4
Battery power circuit module (PCM) with over-charge and over-discharge protection
Operating temperature:
-10 °C + 40 °C
Material: plastic + aluminium
Size: lenght 90 mm, width 33 mm, height 21 mm
Charging: with micro USB 2.0 cable with indication
*Maximum measured value under ideal test conditions
SPECIFICATION
FRONT LIGHT FORCE ALERT 350LM, USB
22
PAP
NOTICE
Do not look directly into the light. To prevent from blinding oncoming riders and walkers always adjust the light angle downwards. Always dismount the light while
cleaning the bicycle and storage outside (protect from rain and snow). Switch the light o if not used. Use the light in well ventilated place outdoors – risk of overheating.
Integrated overheat protection sensor will automatically decrease the light output in case of overheat. The light can be used again at standard operating temperatures.
Light and battery can cause interference of other electrical devices (computers). Battery capacity can be reduced to approximately 70-80% after 300-500 charging cycles.
Battery capacity decreases at lower temperature. Do not expose the light or the battery to a high temperature of + 40 °C (hot place in the car), low temperatures below
0 °C, high humidity and direct sunlight. Store in a cool, dry place, keep away from children, heat source and inammable material. Protect from re and inammable
substances. Do not submerge in water. Light is water-resistant, it can be used in light rain. During heavy rain, it´s reccomended to store on dry place. Do not clean with
water or agressive cleaners. Do not disassemble or otherwise modify the light, battery and accessories. Dispose the light and battery ecologically according to valid
regulations. Do not charge over 5V.
WARRANTY
The warranty cannot be applied to damage caused by exposure to excessive heat, mechanical damage, improper servicing, modications, improper installation or
improper use.
Specications and designs may be changed without prior notice. The current version of the manual can be found on the supplier´s website www.force.bike
Art. 452106 Art. 451725Art. 45176
PACKAGE CONTENTS
OPERATION AND BATTERY LIFE
3 light modes: 100% lighting (2), 75% lighting (2,5h), 50% lighting (4h)
1 ash modes: 6h
Modes switch: short press of button
Swich o the light: for turn OFF the light you have to go threw all modes.
(if there is mode A ON, you have to push power button 4x. If there is mode
B ON you have to push the power button 3x. If there is mode C ON you have to
push the power button 2x. If there is mode D ON you have to push the power
button 1x).
BATTERY CHARGING
Charge the light only with the supplied USB cable/charger, another cable/char-
ger can cause light damage. Always unplug the cable/charger after charging,
store and use in a dry place indoors. Do not leave unattended when charging.
The battery does not charge when the computer is in sleep mode. Always
ensure the USB port of the light by the lid after charging. The battery may get
warm when charging. Several part cycles are better for the battery than1 full
cycle. Avoid ultra-fast high capacity charging. Charge the battery before long
term storage (the battery must be recharged at least once every
6 months). Do not charge or otherwise use the damaged light.
- 4 indicators ON » 100%
- 3 indicators ON » 75%
- 2 indicators ON » 50%
- 1 indicator ashing » 25%
While lights is charging – blue indicators are runing. When the blue
indicators are steady the light is fully chared.
for modes switch press
the button
Bell: for turn on a sound signal (bell)
press the button with bell symbol.
