Force FORCE02E User Manual

11
FORCE E
Installation, Operating & Service Manual
109444-03 - 12/19
Figure 6-3: Recommended Water Piping Direct Connection System (left side)
6 Water Piping (continued)
At least 18"
of straight pipe
for conventional
air separator
To
System
To
System
Optional Circulator Zone
Controlled System
Optional Zone Valve
Controlled System
System
Circulator
System
Zone
Valves
Zone Circulators
Full Port Isolation Valves
Flow Check
From System
Full Port Isolation Valves
Drain Valve
Safety Relief Valve
Pipe within 6" of floor or drain
Drain Valve
IWH
Return
IWH
Supply
Indirect Water Heater (IWH)
Air Separator
& Air Vent
Expansion Tank
Backflow Preventer
Fill Valve
Cold
Water
Return
Full Port Isolation Valves
Unions
Flow Check
IWH Circulator
Full Port Isolation Valve
Unions
Full Port Isolation Valve

Force FORCE02E Specifications

General

Brand	Force
Model	FORCE02E
Category	Boiler
Language	English
