1-18
TRUCK S
CARBURE T ORS-
Continued
Venturi Size
C3 TE -95 1O -K,
C3T F -951O- H, a nd -J
__ ................. 1-1/3 2 inches
C 3T E -9510-B, -0, -E,
and
-G ___ .. _______ 1-3/16 inch es
Anti-Stall Dashpot Clearance
. . . _ . ____ . __ . . __ .. __ 0. 060 -0. 090
Governor By -Pass Jet No .
C3TE-951O- B a nd - E. _ . ... U pp er 29
_________ .. __ ... ____ . . . Lo wer 59
Initial Idle Mixture Adjustment
_ . __________ . _ l-l -l/ 2 t ur ns op en
4-BARREl
Identification
P ar t N o_ appe ars on c hoke pl a te
nang e_
C3 TE - 951 0- F-2 92 HD a nd Manua l-
Shi ft tr an sm is sio n or Auto matic
tran s mis sion.
C3 TE-951O -K -302 HD V -8
C3TE -9 510-L -332 HD V -8
C3TE -9 510- H-4 01 SO V -8
C3TE -95 10 -C -4 77 SO V -8
C3TE - 951 0- D -53 4 SO V-8
Main Metering Jet
Identification No .
PRIMAR Y .
0-
5,000 feet
C3 TE - 951O -F __ __ _______ .. __ . __ 52
C3TE - 951O-K and -L __ __ ____ . __ 52
C3 TE- 951O -H and -0 ___________ 49
C3TE - 951O -C ____ . . . _ __ _ _______ 50
5, 000 - 10 , 000 feet
C3 TE - 951O -F, - K, and -L. _ __ . __ _ 50
C3TE - 951O -C _______ _ __ .. . __ ___ 49
C3TE - 951O -H, and -0 __ __ . ______ 48
10 , 000-15 ,000 feet
C3TE - 9510 -C, -F, -K, and -L ___ __ 48
C3 TE - 951O -H, and -0 ________ . __ 47
SECONDARY
0- 5000 feet
C3TE - 951O -F __________________ 58
C3 TE -95 1O -D _ ____ . _. _________ _ 62
C3 TE - 951O -H, -C, a nd - L. ______ _ 65
5, 000 - 10,000 feet
C3 TE -95 1O -F _____ . __________ 56
C3 TE -95 1O -D_ . _ . _ .. __ ... _ .. ___ 60
C3 TE -95 1O -H, -C_ an d - L. . ______ 63
10 ,000- 1 5,000 fe et
Cm-951O -F ______ ... _______ 54
C3 TE - 95 1O- D ________ ....... . . _ 58
C3 TE - 951O -H, -C, a nd -L __ . . . ___ 61
Power Valve Identification No.
All Alt ilu d es
C3TE - 951O -D, and -F ___ _ . ______ 45
C3 TE -95 1O -C , and -H __ . __ ______ 35
C3 TE -9 51O -K . . . . . ___ . __ . ______ 25
C3 TE -951O- L
0-5 ,000 f ee f.. _____ . .. ____ __ _ 65
5, 000- 1 5, 000 f eet. .. _________ . 40
POWER VALVE OPEN S AT
C3 TE -95 1 0- D
· . . ______ 2 _5-5_5 in ch es of mercury
C3TE- 9 51O- F
_________ 3.5-7.5 inches of mercu ry
C3T E- 951 0- C and -H
· ........... 3· 6 in ch es of m er c ur y
C3 TE -95 1O -K
.. . ..... .... 2-5 in c hes of me rcury
C 3TE -951O- L
· ____ 5- 1/2-8-1 /1 in ches of mercur y
Oepopper Valve
Identification
No.
All ca rburetors _________ . _____ 215
Dry Float initial Setting
PRIM A RY AND SEC O ND A RY
Top of floa t to be p arallel wi th top of
fu el bowl , bowl in ve rted .
Fuel Level Setting
PRIMAR Y AND SECONDARY
Lower edg e of th e sig ht plug opening
_"'- 1/ 16 in ch_
Ventur i Size
Primar y and Seco nd ary 1- 1/ 16 inches
Initial Id le Mixture Adjustment
______ . . . _____ 1-1-1/2 turns ope n
Fast (Cold) Idle Ad j ustment
0 _O IO -0 _O I5 -i nch cle arance between
the f as t idle scre w and th e fas t idle
cam .
Governor Bypass Jet No.
C3 TE -95 1O -F, -K, and -L
Upper. ______ .. ____ __ ____ __ _ 26
Lower _______ . ______ _____ __ _ 25
