Number Fuse amperage
rating
Circuits protected
1 20 amp 4WABS or RABS
module
2 15 amp 4WABS relay (coil),
RABS (diode/resistor),
instrument cluster,
warning chime
3 15 amp Headlamp switch,
radio sense, rear
radio control, Remote
keyless entry module
4 15 amp Power mirrors,
modified vehicle,
power locks w/RKE,
Headlamp switch
(dome), illuminated
entry, Courtesy lamp
switches, Radio
(KAP), Cluster (KAP),
warning chime
5 20 amp Remote keyless entry
module, power door
lock switches,
memory lock
6 10 amp Brake shift interlock,
speed control,
daytime running light
module
7 10 amp Multi-function switch
Roadside emergencies
105
