3. Engage the LH/RH latch rod
hook ends in the front striker
locking holes.
4. Rotate the LH/RH latch handles
forward, and at the same time
slide the seat assembly forward to
engage the strikers. Continue
forward movement until the seat
reaches the end of its travel.
5. Make sure the safety belt is not
twisted, then insert the seat belt
tongue into detachable anchor
until you hear a “click” and feel
the latch engage.
Always latch the vehicle
seat to the floor, whether
the seat is occupied or empty. If
not latched, the seat may cause
injury during a sudden stop.
Quick release captains chair
To remove the seats:
1. Disengage the lap/shoulder belt
from the seat by inserting a key or
small screwdriver into the slot in
eco_rear_captain-seat
Seating and safety restraints
41
