4. Rotate bulb socket
counterclockwise about ¼ turn and
remove from lamp assembly.
5. Carefully pull bulb straight out of
socket and push in the new bulb.
6. Insert the bulb into the parking
lamp assembly. When the grooves in
the plastic base are aligned, push
the bulb into the lamp assembly
until the plastic base contacts the rear of the lamp assembly and turn to
lock.
7. Connect the electrical connector into the rear of the plastic base until
it “snaps.”
8. Align the parking lamp studs with the plastic grommets on the vehicle
and push to snap in place.
9. Install two screws on lamp assembly.
Replacing tail lamp/Backup lamp bulbs
The tail lamp/backup lamp bulbs are
located in the same portion of the
tail lamp assembly, one just below
the other. Follow the same steps to
replace either bulb:
1. Open the liftgate to expose the
lamp assemblies.
2. Remove the four screws and the
lamp assembly from vehicle.
Maintenance and care
191
