Ford 2000 E-150 - Page 136

Fuse/Relay
Location
Fuse Amp
Rating
Power Distribution Box Description
14 30A** Trailer Running Lamps Relay, Trailer
Backup Lamps Relay
15 40A** Main Light Switch
16 50A** RKE Module, Auxiliary Blower Motor Relay
17 30A** Fuel Pump Relay, IDM (Diesel)
18 60A** I/P Fuses 40, 41
19 60A** 4WABS Module
20 20A** Electric Brake Controller
21 50A** Modified Vehicle Power
22 40A** Trailer Battery Charge Relay (Modified
Vehicles Only)
23 60A** Ignition Switch
24 — Not Used
25 20A* NGV Module
26 10A* Generator/Voltage Regulator (Diesel Only)
27 15A* DRL Module, Horn Relay
28 — PCM Diode
29 — Not Used
A — Not Used
B — Not Used
C — Trailer Backup Lamps Relay
D — Trailer Running Lamps Relay
E — Trailer Running Lamps Relay
F — IDM Relay
G — PCM Relay
H — Blower Motor Relay
J — Horn Relay
K — Fuel Pump Relay, IDM Relay (Diesel)
* Mini Fuses ** Maxi Fuses
Roadside emergencies
136
