Ford 2002 Taurus - Page 167

Fuse/relay
location
Fuse amp
rating
Power distribution box
description
1 60A** Fuse junction panel
2 30A** PCM relay
3 60A** Fuse junction panel
4 — Not used
5 — Not used
6 — Not used
7 40A** Starter relay, Ignition switch
8 20A** Transit relay (export only)
9 40A** Cooling fan relays
10 — Not used
11 — Not used
12 — Not used
13 40A** Anti-lock brake module pump
feed
14 — Not used
15 20A* Anti-lock brake module valve
solenoid
16 20A* Fuel pump relay
17 20A* Cell port
18 20A* Cigar lighter
19 15A* Right headlamp
20 — Not used
21 15 A* Left headlamp
22 10A* A/C clutch relay, PCM keep alive
power
23 — Starter motor relay
24 — Fan relay
25 — Wiper speed relay
26 10A* Alternator
27 5A* Rear control unit, Antenna
