Fuse/Relay
Location
Fuse Amp
Rating
Passenger Compartment Fuse
Panel Description
3 15A LH Power Mirror Motor, RH Power
Mirror Motor, Adjustable Pedal Motor,
Memory Module (if equipped)
4 — Not Used
5 20A Console Power Point
6 15A Radio, Compact Disc Changer,
Remote Keyless Entry Module, PSD
(Power Sliding Door) Module RH and
LH, Rear Seat Radio Controller (if
equipped), Rear Seat Entertainment
Module (if equipped)
7 15A Left Rear Turn Lamp, Right Backup
Lamp, Right Stop Lamp, Right Rear
Park Lamp, Right License Lamp, Left
License Lamp, LH Backup Lamp
8 20A Rear Electronic Module (RHF/RH
Sliding/LH Sliding/Liftgate Door Lock
Motors, Aux. Air Blend Door Motor,
Aux. Air Mode Door Motor)
9 10A Cluster, Powertrain Control Module
Relay (coil)
10 15A Heated Backlite Relay (coil), Speed
Control Module, ABS Module or IVD
Module, Heat Seat Switch (RH/LH) (if
equipped), Heated Seat Module
(RH/LH) (if equipped), Cluster, Front
Temp Blend Door Actuator, Brake
Shift Interlock Solenoid, Powertrain
Control Module, Power Sliding Door
Module RH and LH, Reverse Sensing
System, Front A/C Control Head,
Steering Wheel Angle Sensor (if
equipped)
Roadside Emergencies
203
