Fuse/Relay
Location
Fuse Amp
Rating
Passenger Compartment Fuse
Panel Description
11 15A Electric Brake Controller, Brake Shift
Interlock Solenoid, Rear Electronic
Module
12 20A Center High-Mount Stop Lamp
13 10A Right Rear Turn Lamp, Left Stop
Lamp, Left Rear Park Lamp
14 10A Autolamp Sensor, Transmission
Overdrive Cancel Switch, Front
Electronic Module, Compass Module,
Electrochromatic Mirror, Power
Sliding Door Overhead Console
Switch
15 20A Console Power Point
16 10A Cluster
17 20A Cigar Lighter/Powerpoint, Datalink
Connector
18 15A LH Quarter Window Motor, RH
Quarter Window Motor, RH Window
Switch Backlighting, RH Lock Switch
Backlighting, Master Control Switch
(LH) Backlighting, Radio, Video
Cassette Player, Liquid Crystal
Display, Front Electronic Module
19 10A Starter Interrupt Relay (coil)
20 — Not Used
21 — Not Used
22 10A LH Heated Mirror, RH Heated Mirror
23 20A Body Powerpoint, Auxiliary Blower
Relay #1 and #2 Coils
24 — Not Used
25 10A Radio (Anti-theft)
Roadside Emergencies
204
