Ford 2003 Thunderbird - Page 126

Fuse/Relay
Location
Fuse Amp
Rating
Power Distribution Box Description
14 30A** ABS module power
15 — Not used
16 30A** Blower motor
17 — Not used
18 40A** PCM
19 — Not used
20 — Not used
21 30A** Starter solenoid
22 40A** ABS motor
23 — Not used (fuse plug)
24 30A** Wiper relay
Relay 01 — Not used
Relay 02 — Not used
Relay 03 Mini Relay Coil-on-plug and HEGOs
Relay 04 Mini Relay Heated wiper park relay
Relay 05 Mini Relay Auxiliary coolant pump
Relay 06 Mini Relay Horn
Relay 07 — Not used
Relay 08 Mini Relay A/C clutch
Relay 09 60A** Cooling fan motor
Relay 10 Standard
Relay
Blower motor
Relay 11 — Not used
Relay 12 — Not used
Relay 13 — Not used
Relay 14 Standard
Relay
PCM
Relay 15 Standard
Relay
Starter motor
Diode — PCM relay coil
*Mini fuses **Cartridge fuses
2003 Thunderbird (tbr)
Owners Guide (post-2002-fmt)
USA English (fus)
Roadside Emergencies
126
