The fuses are coded as follows.
Fuse/Relay
Location
Fuse Amp
Rating
Passenger Compartment Fuse
Panel Description
R17 — Starter relay
R18 – Rear intermittent relay
R19 — Front wiper intermittent relay
R20 — Not used
R21 — Not used
R22 — Decklid/Liftgate release relay
R23 — Horn relay
R24 — Battery saver relay
R25 — Rear defrost relay
30 10A Light switch
31 15A Radio
32 15A Turn signal
2004 Focus (foc)
Owners Guide (post-2002-fmt)
USA English (fus)
Roadside Emergencies
130
