Ford 2004 Ranger User Manual

Fuse/Relay
Location
Fuse Amp
Rating
Power Distribution Box
Description
14 — Not used
15 30A** Anti-lock Brake System (ABS)
(solenoids)
16 — Not used
17 40A** ABS (motor)
18 — Not used
19 — Not used
20 — Not used
21 10A* PCM
22 — Not used
23 20A* Fuel pump
24 — Not used
25 10A* A/C clutch solenoid
26 — Not used
27 20A* 4x4 module
28 — Not used
29 — Not used
30 — Not used
31 15A* Foglamps
32 — Not used
33 — Not used
34 — Not used
35 — Not used
36 — Not used
37 — Not used
38 7.5A* Trailer tow (right turn)
39 — Not used
40 — Not used
41 15A* HEGOs
42 7.5A* Trailer tow (left turn)
43 — Not used
