6. Locate the vertical adjuster for
each headlamp. Adjust the aim by
turning the adjuster control either
clockwise (to adjust down) or
counterclockwise (to adjust up).
7. On the wall or screen, locate the
high intensity area of the beam
pattern. Place the left edge of the
high intensity area even with the
vertical line corresponding to the
headlamp under adjustment.
Note: Horizontal aiming is not required for this vehicle and is
non-adjustable.
TURN SIGNAL CONTROL
• Push down to activate the left
turn signal.
• Push up to activate the right turn
signal.
INTERIOR LAMPS
COURTESY/READING LAMPS (IF EQUIPPED)
The courtesy lamp lights when:
• any door is opened.
• the instrument panel dimmer
switch is held up until the
courtesy lamps come on.
• the remote entry controls are
pressed and the ignition is OFF.
The reading lamps can be turned on by moving the switch on the dome
lamp to either the left or the right.
2004 Ranger (ran)
Owners Guide (post-2002-fmt)
USA English (fus)
Lights
39
