Cutaway/commercial stripped chassis models
E-350 – inches (mm) E-Super Duty –
inches (mm)
(1) Overall height Refer to Body Builder for specifications.
(2) Track front/rear Cutaway:
69.4 (1763)
SRW: 72.1 (1831)
DRW: 73.2 (1859)
Stripped Chassis:
69.4 (1763)
SRW: 66.4 (1687)
DRW: 73.2 (1859)
69.4 (1763)/
77.7 (1974)
(3) Overall width Refer to Body Builder for specifications.
(4) Wheelbase 138.0 (3505)
158.0 (4013)
176.0 (4470)
158.0 (4013)
176.0 (4470)
(5) Overall length Refer to Body Builder for specifications.
4
5
