• Do not tow a trailer until your vehicle has been driven at least 500
miles (800 km).
• Refer to the instructions included with towing accessories for the
proper installation and adjustment specifications.
Do not exceed the maximum loads listed on the Safety Compliance
Certification label. For load specification terms found on the label, refer
to Vehicle loading in this chapter. Remember to figure in the tongue
load of your loaded vehicle when figuring the total vehicle weight.
4x2
GCWR (Gross Combined Weight Rating)/Trailer weights
Engine Axle ratio Maximum
GCWR - lb.
(kg)
Trailer Weight
Range - lb.
(kg)
0-Maximum
4.0L SOHC All 9600 (4354) 0–5260 (0-2386)
Notes: For high altitude operation, reduce GCW by 2% per 1,000 ft.
(300 meters) elevation. For definition of terms and instructions on
calculating your vehicle’s load, refer to Vehicle loading in this chapter.
Maximum trailer weights shown. The combined weight of the
completed towing vehicle and the loaded trailer must not exceed the
GCWR.
4x4
GCWR (Gross Combined Weight Rating)/Trailer Weights
Engine Axle ratio Maximum
GCWR - lb.
(kg)
Trailer Weight
Range
(0-Maximum) -
lb. (kg)
4.0L SOHC All 9600 (4354) 0–5040 (0-2286)
Notes: For high altitude operation, reduce GCW by 2% per 1,000 ft.
(300 meters) elevation. For definition of terms and instructions on
calculating your vehicle’s load, refer to Vehicle loading in this chapter.
Maximum trailer weights shown. The combined weight of the
completed towing vehicle and the loaded trailer must not exceed the
GCWR.
2005 Explorer Sport Trac (p27)
Owners Guide (post-2002-fmt)
USA (fus)
Tires, Wheels and Loading
162
