The fuses are:
Fuse/Relay
Location
Fuse Amp
Rating
Passenger Compartment Fuse
Panel Description
1 5A Mirrors
2 15A Ignition
3 7.5A Trailer tow right-hand stop/turn
lamps
4 Not used
5 15A Park lamps, Autolamps,
Instrument panel dimming, Trailer
tow
6 7.5A Cluster
7 7.5A Trailer tow left-hand stop/turn
lamps
8 Not used
9 7.5A Speed control, Anti-lock Brake
System (ABS), 4x4, Powertrain
Control Module (PCM), Park
interlock, Keyless entry
10 10A Air bags
2005 Explorer Sport Trac (p27)
Owners Guide (post-2002-fmt)
USA (fus)
Roadside Emergencies
190
