Ford 2005 Explorer - Page 193

The high-current fuses are:
Fuse/Relay
Location
Fuse Amp
Rating
Power Distribution Box Description
1 50A** I/P fuse panel
2 — Not used
3 30A** Powertrain control
4 20A** Power point
5 — Not used
6 — Not used
7 40A** Blower motor
8 30A** Starter motor
9 20A** Wiper motor
10 20A** Rear window/roof
11 50A** Adrenalin audio
12 — Not used
13 — Not used
14 25A** Ignition switch
15 20A** Rear power point
16 50A** Anti-lock Brake System (ABS) pump motor
17 — Not used
18 — Not used
19 20A** Cigar lighter, OBD II
20 20A** 4x4 motor
21 30A* ABS module
22 15A* 4x4 module
23 15A* Trailer tow
24 10A* Powertrain Control Module (PCM) memory
25 — Not used
26 — Not used
27 15A* Daytime Running Lamps (DRL)
28 10A* A/C clutch
29 25A* Headlamps
30 20A* Fuel pump
2005 Explorer Sport Trac (p27)
Owners Guide (post-2002-fmt)
USA (fus)
Roadside Emergencies
193
