Ford 2009 F-150 User Manual

Fuse/Relay
Location
Fuse Amp
Rating
Protected Circuits
35 10A Rear park assist
36 5A PATS transceiver
37 10A Not used (spare)
38 20A Subwoofer
39 20A Radio, Navigation display
40 20A Not used (spare)
41 15A EC mirror, Door lock switch
illumination, Radio accessory
delay
42 10A Not used (spare)
43 10A Heated mirror/backlight relay,
Rain sensor, Reverse camera
44 10A Not used (spare)
45 5A Front wiper logic, Blower motor
relay
46 7.5A Occupant classification sensor
(OCS)
47 30A Circuit
Breaker
Power windows, Moon roof,
Power sliding backlight
48 — Delayed accessory relay (Feeds
fuse 41 and circuit breaker 47)
Power distribution box
The power distribution box is located in the engine compartment. The
power distribution box contains high-current fuses that protect your
vehicle’s main electrical systems from overloads.
WARNING: Always disconnect the battery before servicing high
current fuses.
WARNING: To reduce risk of electrical shock, always replace
the cover to the Power Distribution Box before reconnecting the
battery or refilling fluid reservoirs.
2009 F-150 (f12)
Owners Guide, 2nd Printing
USA (fus)
Roadside Emergencies
319
