Fuse/Relay
Location
Fuse Amp
Rating
Protected Circuits
34 5A Yaw rate sensor, ABS R/S,
Refrigerator relay coil
35 10A Steering rotation sensor, Rear
park assist, Heated seat modules,
AWD, DC/AC inverter
36 5A PATS module
37 10A Not used (spare)
38 20A Not used (spare)
39 20A Radio
40 20A Second row heated seats
41 15A Switch illumination, EC mirror,
Moon roof, Front lock switches,
Radio
42 10A Not used (spare)
43 10A Aux relay, Heated back light relay,
rear wiper
44 10A Not used (spare)
45 5A Relay coils: PDB, Front and rear
wipers, Front blower motor
46 7.5A Occupant Classification Sensor
(OCS), Passenger Airbag
Deactivation Indicator (PADI)
47 30A Circuit
Breaker
Power windows
48 Full ISO relay Delayed accessory relay
Power distribution box
The power distribution box is located in the engine compartment. The
power distribution box contains high-current fuses that protect your
vehicle’s main electrical systems from overloads.
WARNING: Always disconnect the battery before servicing high
current fuses.
2009 Flex (471)
Owners Guide, 2nd Printing
USA (fus)
Roadside Emergencies
290
