Ford 2009 FLEX - Page 289

Fuse/Relay
Location
Fuse Amp
Rating
Protected Circuits
8 10A Low beam headlamps (right)
9 15A Interior lights, Cargo lamps
10 15A Backlighting, Puddle lamps
11 10A All wheel drive
12 7.5A Not used (spare)
13 5A Keypad, Mirror switch, Memory
module, DSM logic, Adjustable
pedals
14 10A Power liftgate module, CID, MGM
15 10A Climate control head
16 15A EFP, Navigation Screen
17 20A All power lock motor feeds,
Liftgate release
18 20A 2nd row power seat, Front heated
seats
19 25A Moon roof
20 15A OBDII connector, Memory seat
21 15A Fog lamps
22 15A Park lamps, License lamps
23 15A High beam headlamps
24 20A Horn relay
25 10A Demand lamps/Interior lamps,
Power fold seat (2nd row)
26 10A Instrument panel cluster
27 20A Ignition Switch
28 5A Radio, Radio start signal
29 5A Instrument panel cluster
30 5A Overdrive cancel and grade assist
switch
31 10A Not used (spare)
32 10A Restraint control module
33 10A Battery charge relay
