On the 2.5L I4 engine, be sure the
notch in the dipstick flange is
aligned with the V on the engine
when reinserting it.
• 2.5L I4 engine
• 3.0L/3.5L V6 engines
•If the oil level is within this range, the oil level is acceptable. DO
NOT ADD OIL.
• 2.5L I4 engine
• 3.0L/3.5L V6 engines
•If the oil level is below this mark, engine oil must be added to raise
the level within the normal operating range.
Maintenance and Specifications
287
2010 Fusion (fsn)
Owners Guide, 2nd Printing
USA (fus)
