Fuse/Relay
Location
Fuse Amp
Rating
Protected circuits
22 10A* PCM, Auxiliary connector
23 10A* Right low beam headlamp
24 10A* A/C clutch solenoid
25 10A* Left low beam headlamp
26 10A* Mass air flow sensor, Brake
switch, Backup lamps relay
27 — Not used
28 15A* PCM vehicle power 1
29 15A* Auxiliary connector
30A 70A Relay Cooling fan high relay
30B
30C — Cooling fan low relay
30D — Start lock relay
31A — Backup lamp relay
31B — Fuel pump relay
31C — DRL relay
31D — Low beam headlamps relay
31E — Not used
31F — Not used
32 — Cooling fan diode
33 — Fuel pump relay diode
34 — Gear shifter diode
35 10A* PCM ignition sensor
36 — Not used
*Mini fuse **Cartridge fuse
CHANGING THE TIRES
If you get a flat tire while driving, do not apply the brake heavily.
Instead, gradually decrease your speed. Hold the steering wheel firmly
and slowly move to a safe place on the side of the road.
Note: The tire pressure monitoring system (TPMS) indicator light will
illuminate when the spare tire is in use. To restore the full functionality
of the monitoring system, all road wheels equipped with tire pressure
monitoring sensors must be mounted on the vehicle.
Roadside Emergencies
181
