Fuse/Relay
Location
Fuse Amp
Rating
Protected Circuits
29 20A Radio, Multi-function display
screen, Electronic finish panel,
SYNC威 module
30 15A Front park lamps , Side repeater
lamps (China only)
31 5A Not used (spare)
32 15A Lock switch backlighting, Moon
roof, Power windows,
Compass/auto-dimming rear view
mirror
33 10A Not used (spare)
34 10A Reverse sensing system, Rearview
camera, Blind spot monitor
35 5A Heads-up display, Headlamp
leveling
36 10A Not used (spare) , Rear fog lamp
module (China only)
37 10A Climate control
38 10A Not used (spare)
39 15A High beam headlamps
40 10A Rear park lamps, license plate
lamps
41 7.5A Occupant classification sensor
(OCS), Restraints control module
42 5A Grade assist control switch
43 10A Not used (spare)
44 10A Not used (spare)
45 5A Not used (spare)
46 10A Climate control
47 15A Not used (spare)
48 30A Circuit
Breaker
Power windows
49 — Delayed accessory relay
