Intelligent all-wheel drive
(AWD) (if equipped) + other
gauges
For a description of the other
gauges, see the descriptions listed
previously.
• Intelligent all-wheel drive: shows
the AWD mode that the vehicle is
in. Refer to All-Wheel Drive
(AWD) system in the Driving
chapter.
SelectShift Automatic™ transmission (SST)
This feature allows you to manually shift gears. If your vehicle is
equipped with this feature it will be denoted by an M instead of an L
located in the shift selector indicator. Refer to Automatic transmission
operation in the Driving chapter.
When SST is activated the M will light up in the shift select indicator and
also in the message center.
The selected gear will be displayed
at the bottom of the vertical bar
tachometer (if selected).
The selected gear will be displayed
within the full analog tachometer (if
selected).
F
6
4
RPM
1000
+
2
0
01234.5mi
Intelligent AWD
E
F
6
4
RPM
1000
+
2
0
E
Instrument Cluster
33
2011 Edge (edg)
Owners Guide, 2nd Printing
USA (fus)
