Fuel Gauge: The fuel gauge will indicate approximately how much fuel is
left in the fuel tank. The fuel gauge may vary slightly when your vehicle is
moving or on a gradient. The arrow adjacent to the fuel pump symbol
indicates on which side of the vehicle the fuel filler door is located.
Brake Coach Display: The Brake Coach appears after the vehicle has
come to a stop. It coaches you to brake in a manner which maximizes the
amount of energy returned through the regenerative braking system. The
percent displayed is an indication of the regenerative braking efficiency
with 100% representing the maximum amount of energy recovery.
Trip Summary and Lifetime Summary: These will be displayed upon
shutting off the vehicle. Trip Summary will appear first, then Lifetime
Summary will be displayed. You can toggle between these displays using
the up and down arrow keys on the left hand steering wheel controls.
Trip Summary data is from the last power cycle, while Lifetime Summary
data is cumulative from the last Lifetime Summary reset done through
the Settings menu in the message center.
Trip Summary:
• Distance - The total distance travelled, distance travelled on battery
power only (EV distance) and regen distance are displayed. Regen
distance is the estimated range gained from energy recaptured
through regenerative braking.
• Energy Use - The average fuel economy and total fuel used are
displayed. In addition for Energi, the total electrical energy used while
in Plug-in Power Mode is displayed in kilowatt hours (kWh). Trip
Summary average fuel economy will be shown in blue if better than
your lifetime average fuel economy.
• Brake Score - The average percentage of braking energy recaptured
and returned to the high voltage battery through regenerative braking.
The brake score will be shown in blue if greater than (better than) the
lifetime brake score.
Lifetime Summary:
• Distance - The distance travelled on battery power only (EV distance)
and regen distance are displayed. Regen distance is the estimated
range gained from energy recaptured through regenerative braking.
• Energy Use - Average fuel economy.
• Brake Score - The average percentage of braking energy recaptured
and returned to the high voltage battery through regenerative braking.
Instrument Cluster 105
2013 C-Max Full Hybrid (34h)
Owners Guide gf, 2nd Printing
USA (fus)
