4. Remove the wing nut.
5. Gently pull the lamp assembly
away from the vehicle
6. Disconnect the electrical
connector.
7. Remove the bulb holder.
8. Gently press the bulb into the
bulb holder, turn the bulb
counterclockwise, and remove the
bulb.
A. Reverse lamp
B. Tail lamp
Install the new bulb in reverse order.
Replacing the License Plate Lamp Bulb
1. Carefully release the spring clip.
2. Remove the lamp.
3. Remove the bulb.
Install the new bulb in reverse
order.
3
2
1
Maintenance 301
2013 C-Max Full Hybrid (34h)
Owners Guide gf, 2nd Printing
USA (fus)
