MANUAL HEATING AND AIR CONDITIONING SYSTEM
A. Power: Press the button to turn the system on and off. When the
system is off, outside air is prevented from entering the vehicle.
B. Air distribution control: Press to set the air distribution to a
position listed below:
Distributes air through the windshield defroster vents,
de-mister vents and floor vents.
Distributes air through the instrument panel vents.
Distributes air through the instrument panel vents, floor vents,
and de-mister vents.
Distributes air through the floor vents.
C. A/C: Press the button to turn air conditioning on or off. Air
conditioning cools the vehicle using outside air. To improve air
conditioning when starting your vehicle, drive with the windows slightly
open for two to three minutes.
Climate Control 151
