Changing the Air Filter Element
3.5L V6 engine
2.0L EcoBoost威 engine
3.5L V6 EcoBoost威 engine
1. On the passenger’s side of the air filter housing, release the two
clamps from the air filter housing cover.
2. Lift the passenger’s side of the cover and push the cover toward the
passenger’s side. Release the three tabs on the cover from the three slots
in the driver’s side of the housing.
3. Carefully separate the cover from the housing.
4. Remove the air filter element from the housing.
340 Maintenance
2013 Explorer (exp)
Owners Guide gf, 2nd Printing
USA (fus)
