Display Mode
Use the up/down arrow buttons to choose between the
following display options.
Display mode ā Option 1 Option 2 Option 3 ā Option 4
XXX mi (km) to empty X
Fuel gauge XXXX
Bar tachometer X X
Round tachometer X X
Engine coolant temp
gauge
X
Total odometer (lower
left corner)
XXXX
ā Vehicles with Intelligent AWD only. You can choose to have only the
fuel gauge show in this mode. Refer to Display > Gauge Display
found in the table under the Settings section later in this chapter.
Regardless of display mode chosen, when SelectShift Automaticā¢
transmission (SST) is activated, the cluster will change to the round
tachometer if not already selected. After the round tachometer
displays, other display modes with the bar tachometer can also be
chosen.
ā¢ XXX mi (km) to empty: Shows approximate fuel level before the fuel
tank reaches empty. The value is dynamic and can change (raise or
lower) depending on driving style.
ā¢ Fuel gauge: Indicates approximately how much fuel is left in the fuel
tank. The fuel gauge may vary slightly when the vehicle is in motion or
on a grade. When the fuel level becomes low, the level indicator will
change to amber. When the fuel level becomes critically low, the level
indicator will change to red.
Note: When a MyKeyåØ is in use, low fuel warnings will display earlier.
The fuel icon and arrow indicates which side of the vehicle the fuel
filler door is located.
ā¢ Bar/Round tachometer: Indicates the engine speed in revolutions per
minute. Driving with your tachometer pointer continuously at the top
of the scale may damage the engine. During SelectShift Automaticā¢
transmission (SST) use, the currently selected gear will appear in the
display.
124 Information Displays
2013 Flex (471)
Owners Guide gf, 1st Printing
USA (fus)
