2. Lift the passenger’s side of the cover and push the
cover toward the passenger’s side. Release the three
tabs on the cover from the three slots in the driver’s
side of the housing.
3. Carefully separate the cover from the housing.
4. Remove the air filter element from the housing.
5. Wipe the cover and the housing clean to remove any
dirt or debris and to make sure the cover seals to the
housing.
6. Install a new air filter element. Be careful not to crimp the filter element
edges between the housing and the cover. This could cause filter damage
and allow unfiltered air to enter the engine if not properly seated.
7. Lower the driver’s side of the cover and slide the three tabs on the
cover into the three slots in the housing.
8. Lower the passenger’s side of the cover. Engage the two clamps to
secure the cover to the housing.
Maintenance 323
2013 Flex (471)
Owners Guide gf, 1st Printing
USA (fus)
