Protected componentsFuse amp ratingFuse or relay number
Not used (spare)
10A
2
7
Not used (spare)
10A
2
8
Not used (spare)
10A
2
9
Keypad
5A
2
10
Not used
5A
2
11
Climate control, Gear shift
7.5A
2
12
Steering wheel column, Cluster, Datalink
logic
7.5A
2
13
Not used
10A
2
14
Datalink/Gateway module
10A
2
15
Not used (spare)
15A
1
16
Not used (spare)
5A
2
17
Ignition, Push button stop/start
5A
2
18
Passenger airbag disabled indicator,
Transmission range
5A
2
19
Not used (spare)
5A
2
20
Humid and incar temp
5A
2
21
Occupant classification sensor
5A
2
22
Delayed accessory (Power inverter logic,
Moonroof logic)
10A
1
23
Central lock/unlock
30A
1
24
Driver door (window, mirror)
30A
1
25
Front passenger door (window, mirror)
30A
1
26
Moonroof
30A
1
27
239
Fusion/Mondeo (CC7)
Fuses
