CPR © 2021 FORD MOTOR COMPANY
DEARBORN, MICHIGAN 48121
12/2021
Page 5 of 22
STABILIZATION / LIFTING POINTS
WARNING:
The vehicle should be lifted or manipulated only by personal that are properly trained and
equipped. Use caution to ensure you never come into contact with the high voltage battery or
other high voltage components while lifting or manipulating the vehicle.
The high voltage battery is located behind an underbody air shield under the vehicle. When lifting
or stabilizing only use the designated lift areas, as shown.
DO NOT USE THE HIGH VOLTAGE BATTERY TO LIFT OR STABILIZE
PLACE COPY HERE
PLACE COPY HERE
PLACE COPY HERE
STUD FOR
MISSING NUT
STUD FOR
MISSING NUT
STUD FOR
MISSING NUT
