29. Install the catalytic converter. For additional information, refer to Section 309-00.
30. Inspect the valve cover gasket. Install a new gasket, if necessary.
31. Position the valve cover.
1. Install the studbolts.
2. Install the bolts.
32. Connect the wiring harness anchors to the valve cover studs.
33. Attach the catalyst monitor and heated oxygen sensor electrical connectors to the bracket. Connect the electrical connectors.
34. Connect the throttle cables.
Connect the accelerator cable.
If equipped, connect the speed control actuator cable.
35. Install the spark plugs. For additional information, refer to Section 303-07A.
36. Install the air cleaner outlet pipe. For additional information, refer to Section 303-12.
37. Connect the battery ground cable. For additional information, refer to Section 414-01.
2002 Escape Workshop Manual
